Technical Data
Accuracy Class ISO 376	Class 00	Class 0.5	Class 1
Nominal Load	10-2000 kN	10-2000 kN	10-2000 kN
Relative Error (Repeatability)	≤ ±0.020%	≤ ±0.045%	≤ ±0.080%
Relative Error (Interpolation)	≤ ±0.020%	≤ ±0.040%	≤ ±0.050%
Relative Error (Reversibility)	≤ ±0.030%	≤ ±0.050%	≤ ±0.090%
Relative Error (Zero)	≤ ±0.005% F.S.	≤ ±0.010% F.S.	≤ ±0.010% F.S.
Linearity	≤ ±0.02% F.S, 2000kN: ≤ ±0.05%
Hysteresis	≤ ±0.02% F.S, 2000kN: ≤ ±0.05%
Temperature Effect on Zero (10°C)	≤ ±0.015% F.S.
Temperature Effect on Sensitivity (10°C)	≤ ±0.010% F.S.
Nominal Sensitivity	2 mV/V
Sensitivity Tolerance	≤ ±0.1% F.S.
Input Resistance (10-50 kN)	700±2 Ω
Output Resistance (10-50 kN)	705±2 Ω
Input Resistance (100-2000 kN)	350±2 Ω
Output Resistance (100-2000 kN)	352±2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ±0.2% F.S.
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1-15 V
Maximum Supply Voltage	18 V
Mechanical Limits (Service Load)	120%
Mechanical Limits (Max Load)	150%
Mechanical Limits (Breaking Load)	>300%
Mechanical Limits (Transverse Load)	100%
Mechanical Limits (Dynamic Load)	75%
Displacement at Nominal Load	~0.2 mm (2000 kN: ~0.35 mm)
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-10/+70 °C
Storage Temperature	-20/+80 °C
Weight	~4.5 - 48 kg
Protection Class (EN 60529)	IP67
Execution Material	Stainless Steel
Cable Length	5 m
