Technical Data
Accuracy Class	ISO 376 class 1 (from 10% to 100% F.S.)
Accuracy	≤ ±0.05 % F.S.
Nominal Load (kg)	100, 200, 500, 1000, 2500, 5000
Measurement Units	kg, t, lb, kN, daN, N
Service Temperature	0 … +50 °C
Storage Temperature	0 … +60 °C
Relative Humidity	< 90% not condensed
Temperature Effect on Zero (1°C)	≤ ±0.015 %
Temperature Effect on Sensitivity (1°C)	≤ ±0.005 %
Internal Resolution	16 bit
Readings per Second	10 (100 ms)
LCD Display	Backlit, 5 digits, 13 mm height
Resolution Steps	1, 2, 5, 10
Digital Filter	Adjustable from 0 to 5
Zero Function	100% F.S.
Peak Function	Compression / Tension
Menu Lock Function	Yes (programming protection)
Communication Port	USB 2.0
Transmission Type	On request or continuous
Max Transmission Rate	10 data/sec
Max Cable Length	5 m
Power Supply	Li-Ion battery 3.6V 1800mAh
Autonomy	50 hours (without backlight)
Recharge	USB port (5Vdc)
Service Load	100% F.S.
Max Permissible Load	150% F.S.
Breaking Load	>300% F.S.
Max Dynamic Load	75% F.S.
Protection Class	IP40
Case	Aluminium
Sensor Material	Stainless steel
Weight	∼ 1.5 kg
