Technical Data
Accuracy class (OIML R60)	C1	C2		C3
Legal divisions	1000	2000		3000
Nominal load (Emax)	100, 250, 500 kg; 1, 2.5, 5, 7.5, 10, 20 t; 30, 50, 75, 100, 150, 200 t
Min. verification interval (Vmin)	Emax / 10000
Combined error	≤ ± 0.045 %	≤ ± 0.035 %		≤ ± 0.028 %
Non repeatability	≤ ± 0.015 %	≤ ± 0.010 %		≤ ± 0.008 %
Zero return over 30m	≤ ± 0.036 %	≤ ± 0.023 %		≤ ± 0.018 %
Creep at nominal load	Over 30 min.: ≤ ± 0.035 %	Over 30 min.: ≤ ± 0.028 %		Over 30 min.: ≤ ± 0.022 %
	Over 20 and 30 min.: ≤ ± 0.010 %	Over 20 and 30 min.: ≤ ± 0.008 %		Over 20 and 30 min.: ≤ ± 0.005 %
Temperature effect (10 °c)	On zero: ≤ ± 0.030 %	On zero: ≤ ± 0.024 %		On zero: ≤ ± 0.020 %
	On sensitivity: ≤ ± 0.024 %	On sensitivity: ≤ ± 0.017 %		On sensitivity: ≤ ± 0.010 %
Nominal sensitivity	2 mv/v
Calibration tolerance	≤ ± 0.1 %
Input resistance	700 ± 2 Ω
Output resistance	700 ± 2 Ω
Insulation resistance	> 5 GΩ
Zero balance	≤ ± 1 %
Recommended supply voltage	10 v
Nominal supply voltage	1, 15 v
Maximum supply voltage	18 v
Mechanical limit values referred to nominal load	a) Minimum load: 0 %
	b) Service load: 120 %
	c) Max permissible load: 150 %
	d) Breaking load: >300 %
	e) Max transverse load: 50 %
	f) Max permissible dynamic load: 50 %
Nominal Load	100kg…10t	20t...30t	50t..100t	150t...200t
Displacemnet at Nominal load	~0.06mm	~0.16mm	~0.23mm	~0.36mm
Reference temperature	+23 °c
Temperature nominal range	-10 / +40 °c
Service temperature	-20 / +70 °c
Storage temperature	-20 / +80 °c
Weight	~1.3kg	~3.4kg	~9.4kg	~18.2kg
Protection class (en 60529)	IP68 (100h at 1m water column)
Execution material	Stainless steel
Cable length	5 m (on request 10 m)
Fixing screws	Diameter: M8	Diameter: M8	Diameter: M16	Diameter: M16
	Resistance class: 12.9
	Tightening torque: 80 nm	Tightening torque: 80 nm	Tightening torque: 230 nm	Tightening torque: 230 nm
