Technical Data
Type	MRE-M
Version	Crimped-on ring case
Nominal size	63 mm, 100 mm
Accuracy acc. EN 13190	EN 837-1, class 1.6 (nominal size 63 mm) and class 1 (nominal size 100 mm)
Medium / Application	Liquid and gaseous media
Process connection	Thread see table, brass
Measurement system	Bourdon spring bronze
Degree of protection according to EN 60529	MRE-M
Ambient temperature	-20 to 60 °C with case filling
Storage temperature	-20 to 60 °C with case filling
Nominal use temperature acc. EN 13190	20 °C
Pressure load capacity	Of full-scale value
	Nominal size 63 mm				Nominal size 100 mm
Resting load	75%				100%
Dynamic load	65%				90%
Overload	Max. 100%				130%
