Technical data
Pressure Type	Relative: 10 bar, 20 bar Absolute: 50, 100, 250, 350, 500, 700 bar
Linearity & Hysteresis	≤ ± 0.50 % (low range), ≤ ± 0.20 % (high range)
Temperature Effect (1°C) on Zero	≤ ± 0.020 %
Temperature Effect (1°C) on Sensitivity	≤ ± 0.015 %
Nominal Sensitivity	1 mV/V ≤ ± 0.5 %, 2 mV/V ≤ ± 0.5 %
Nominal Power Supply	1-15 V
Max. Power Supply	18 V
Input Resistance	560 Ω typical
Output Resistance	500 Ω typical
Insulation Resistance	>2 GΩ
Zero Balance	≤ ± 0.5 %
Response Frequency	20 to 100 kHz
Service Pressure	1
Max. Permissible Pressure	1.5
Breaking Pressure	> 300 %
Highly Dynamic Pressure	0.75
Reference Temperature	+23 °C
Working Temperature Range	-10 / +110 °C
Storage Temperature Range	-20 / +110 °C
Standard Process Coupling	1/4" Gas FEMALE / BSP FEMALE
Recommended Gasket	USIT A 63-11
Tightening Wrench	22 mm
Tightening Torque	25 Nm
Protection Class (EN 60529)	IP67
Sensor Execution Material	Stainless Steel 17-4 PH
Connector	M12×1 Male
Cable	PVC molded, shielded
Length	3 meters
