Technical Data
Independent Channels	1 (CH1)
Accuracy	≤ ±0.010 %
Linearity Error	≤ ±0.010 %
Internal Resolution	24 bit
Strain Gauge Input (CH1)	±2 mV/V and ±3 mV/V (max ±3.5 mV/V)
Resolution (Strain Gauge)	±50,000 div
Sensor Supply	5 V at switching frequency (±3%)
Connection System	4 or 6 wire
Sensor Resistance Range	100 Ω to 2000 Ω
Parallel Sensors	4x 350 Ω or 8x 700 Ω
Amplified Input (Voltage)	±10 V and ±5 V
Resolution (Voltage Input)	±50,000 div
Supply for Amplified Sensors	20 Vdc (±1 Vdc)
Amplified Input (Current)	0–20 mA, 4–20 mA
Resolution (Current Input)	+50,000 div
Potentiometer Input	±5 V, R min. 1 kΩ
Potentiometer Supply	5 Vdc
Display Type	6 digit red LED, 7 segments
Character Height	~13 mm
Sensor Calibration	1–5 points, pos. and neg.
Zero Function	100% of full scale
Autozero Threshold/Time	Programmable
Peak Function	Positive and Negative
Discharge Function	Yes
Key Lock	Password protection
Programmable Resolution	1 … 100
Digital Filter	0 … 5
Decimal Point Position	0 … 5
Conversion Speed	2.5 to 1200 samples/sec
Programmable Keys	F1
Set Points	4
Digital Inputs	4
Relay Outputs	4
Max Contact Voltage	220 Vdc – 250 Vac
Max Current	500 mA
Max Power	60 W – 62.5 VA
USB Port	Type B, Max Cable Length 3.5 m
Operating Temp (Nominal)	0 … +50 °C
Max Operating Temp	0 … +50 °C
Storage Temp	-20 … +70 °C
Temp Effect on Zero (10°C)	≤ ±0.005 %
Temp Effect on FS (10°C)	≤ ±0.005 %
Power Supply	230 Vac ±10 %
Frequency	50/60 Hz
External Fuse	250 mA / 250 V
Max Power	10 VA
Enclosure Type	DIN 43700
Enclosure Material	NORYL UL94 V-0
Front/Rear Panel	UL94 V-2
Protection (Front Panel)	IP40
Environmental Pollution Degree	1
Dimensions (HxWxD)	72 x 144 x 150 mm
Panel Cutout	68 x 138 mm
Weight	~0.8 kg
