Technical Data
Accuracy	≤ ± 0.02%
Linearity Error	≤ ± 0.02%
Internal Division	24 bit
Strain Gauge Input	± 2 mV/V (max ± 2.5 mV/V)
Resolution (Strain Gauge)	± 20,000 div
Power Supply for Transducers	5 Vdc
Transducer Resistance	100 Ω to 2000 Ω
Transducers Connected in Parallel	4@350 Ω or 8@700 Ω
Voltage Input (Amplified Transducer)	± 10 V / ± 5 V
Resolution (Voltage Input)	± 20,000 div
Power Supply for Voltage Input	18 Vdc (± 1 Vdc)
Current Input (Amplified Transducer)	0-20 mA, 4-20 mA
Resolution (Current Input)	± 20,000 div
Power Supply for Current Input	18 Vdc (± 1 Vdc)
Input for Potentiometers	5 Vdc, R min. 1 kΩ
Sensor Calibration	Positive and Negative range, Full Scale
Calibration Type	Digital calibration for both positive and negative ranges
Display Color	Red
Number of Digits	5
Character Height	14 mm
Programmable Set Points	2
Digital Input	1 programmable function
Relays Output	2 (24 Vdc, 500 mA, 12 W max)
Acquisition Frequency	From 2.5 to 1200 samples per second
Nominal Temperature Range	0... +50 °C
Max Temperature Range	0... +50 °C
Storage Temperature Range	-20... +70 °C
Effects on 10°C Temp. Variation (Zero)	≤ ± 0.005%
Effects on 10°C Temp. Variation (Full Scale)	≤ ± 0.005%
External Power Supply	230 Vac ± 10%, 50/60 Hz
Protection Fuse	250 mA / 250 V
Max Power	10 VA
Protection Class (EN 60529)	IP40 (only front panel)
Panel Material	NORYL UL94 V-O
Material Front and Rear Panel	UL94 V-2
Environmental Pollution Grade	1
Dimensions	48 x 96 x 153 mm
Hole Gauge (A x L)	44.5 x 91.5 mm
Weight	∼ 0.5 kg
Optional Features	Analog output for current (4-20 mA) or voltage (0-5 V, 0-10 V, ±10 V, ±5 V)
Optional Power Supply	115 Vac or 24 Vdc
