Technical Data
Temperature range	50...1200 °C
Block Dimensions	Ø 36 x 160 mm
Insert Dimensions	Ø 34 x 130 mm, removable insert, 60 mm insulator
Accuracy	±3 °C
Temperature stability	±0.1 °C
Resolution of the temperature display	1 °C
Heating Time	100 minutes to 1200 °C
Cooling Time	5 h (1200 °C down to 200 °C)
Radial Uniformity	+/- 0.05 ºC @ 50 ºC
	+/- 0.15 ºC @ 650 ºC
	+/- 0.20 ºC @ 1100 ºC
Axial Uniformity (20 mm)	+/- 0.15 ºC @ 50 ºC
	+/- 0.25 ºC @ 650 ºC
	+/- 0.25 ºC @ 1100 ºC
Stabilization time	10 minutes
Power supply	230 VAC (±10 %), 3.5, 50/60 Hz
	115 VAC (±10 %), 7 A, 50/60 Hz
Power consumption	800 W
Size (HxWxD)	350 x 205 x 325 mm
Weight	12.6 kg
