Technical Data
Temperature range	Room temperature...650 °C
Dimension of the calibration insert	Ø 28 x 150 mm (calibration insert easily exchangeable)
Dry block
Accuracy	±1 °C
Temperature stability	±0.1 °C
Resolution of the temperature display	1 °C
Reference temperature sensor	internal, fixed installation
Dimensions
->Width	150mm
->Hight	330 + 70mm (Handle)
->Depth	270mm
Weight	Approx. 7.5 kg
Power supply	115 V or 230 V Nominal voltage (two variants)
Power consumption	Approx. 1000 W
Display and control	2-line, 4-digit digital display red / green, unit °C / °F
Approvlas	CE, RoHS, REACH, EAC, UKCA, CT, DNV
Calibration insert
Bore holes (mm)	Material
1x Ø 3.5, 1x Ø 6.5, 1x Ø 13.5	Brass
1x Ø 6.5	Brass
2x Ø 3.5	Brass
1x Ø 3.5, 1x Ø 4.5	Brass
1x Ø 3.5, 1x Ø 6.5	Brass
1x Ø 3.5, 1x Ø 8.5	Brass
Without bore holes	Brass
Calibration insert incl. 1 bore hole of choice	Brass
Each additional bore hole	Brass
