Technical Data
Accuracy	≤ ± 0.01%
Linearity Error	≤ ± 0.01%
Standard Input Signal	2 mV/V
Input Impedance	1010 Ω
Connectable Load Cells	4 (350 Ω) or 8 (700 Ω)
Bridge Excitation Voltage	5 Vdc ±4%
Serial Output	RS232C, RS485
Communication Speed	max 115200 Baud
Standard Resolution (2mV/V)	± 200,000 div
Internal Resolution	1,000,000 div
Readings per Second (filter 0)	300 (3.3ms)
Nominal Working Temperature	0... +50°C
Max Working Temperature	0... +70°C
Storage Temperature	-20... +85°C
Temperature Effect (Zero)	≤ ± 0.01% per 10°C
Temperature Effect (Full Scale)	≤ ± 0.01% per 10°C
Power Supply	11... 26 Vdc
Current Consumption	max 180 mA
External Protection Fuse	Fast 315 mA, 250 V
Protection Class (EN 60529)	IP65
Case Material	Aluminium
Dimensions (HxLxW)	80 x 125 x 58 mm
Weight	∼ 0.6 kg
