Technical Data
Nominal load	2.5 - 5 kN 10 - 25 kN	50 kN 100 kN	200 kN 300 kN	500 kN	750 kN 1 MN	2 MN	3 MN 5 MN
Repeatability (b)	≤ ±0.145 %
Interpolation (fc)	≤ ±0.090 %
Reversibility (u)	≤ ±0.240 %
Zero error (fo)	≤ ±0.030 % F.S.
Linearity	≤ ±0.05 % F.S.						≤ ±0.10 % F.S.
Hysteresis	≤ ±0.05 % F.S.						≤ ±0.10 % F.S.
Temp. effect on zero	≤ ±0.028 % F.S.
Temp. effect on sens.	≤ ±0.024 % F.S.
Transverse load (10%)	≤ ±0.030 % F.S.
Nominal Sensitivity	2 mV/V
Calibration Tolerance	≤ ±0.1 % F.S.
Input Resistance	800 ± 20 Ω				430 ± 20 Ω
Output Resistance	705 ± 2 Ω				352 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ±1 % F.S.
Recommended Supply	10 V
Nominal Supply Range	1–15 V
Max Supply Voltage	18 V
Service Load Limit	120 %
Max Load Limit	150 %
Breaking Load	> 300 %
Max Transverse Load	100 %
Max Dynamic Load	75 %
Displacement @ Nom. Load	∼0.06 mm	∼0.09 mm	∼0.17 mm	∼0.17 mm	∼0.23 mm	∼0.21 mm	∼0.21 mm
Weight (kg)	∼1.6	∼2.5	∼5.8	∼6.8	∼16.5	∼35	∼63
