Technical Data
Version	Cable drum housing
Dimensions	234 mm / 285 mm x 85.5 mm (D / H x D)
Materials (Not in contact with medium)	PP plastic, aluminium, glass front window
Materials (In contact with medium)	Stainless steel 1.4571
Measuring range	-40…150 °C
Medium / Application	Liquid and solid media (bulk material)
Immersion tube length	75 mm
Immersion tube length	20 mm
Process connection	Without
Pressure rating	PN 25
Display	3 ½ digit, 7 segment LCD, 25 mm high
Resolution	0.1 K in the range -40…150 °C
Measuring rate	3 s
Ambient temperature	5…60 °C
Storage temperature	5…60 °C
Degree of protection EN 60529	IP40
Electrical data
Measuring element	Pt1000 / 2-wire / Class B
Accuracy	±0.5 % of range ±1 digit
Electrical connection	FEP cable, shielded, 2 x 0.14 mm², 35 m long „extendable“
Supply voltage	Lithium battery, 10 years service life (display unit)
