Technical Data
Version	Straight
Dimensions
-> Housing	140 x 150 x 30 (W x H x D)
-> With mounting plate	170 x 150 x 35 (W x H x D)
Materials (Not in contact with medium)	Housing; Powder-coated steel, glass front window
Measuring range	-60…650 °C
Medium / Application	Liquid and gaseous media
Display	3½ digit, 7 segment LCD, 25 mm high
Resolution	0.1 K in the range <200 °C
	1 K in the range >200 °C
Measuring rate	3 s
Ambient temperature	5…60 °C
Storage temperature	5…60 °C
Degree of protection EN 60529	IP65
Approvals	EU RO Mutual Recognition Type Approval Certificate (Marine ver-sion only). Covers: ABS, BV, CCS, CRS, DNV, IRS, KR, LR, ClassNK, PRS, RINA, RS
Electrical data
Measuring element	Pt1000 / 2-wire / Class B
Accuracy	±1 % of range ±1 digit
Electrical connection	4-pin plug connector M12 x 1
Supply voltage	Loop supply 15…26 VDC Solar cell, 80 lux (as backup for display)
Analogue output
Current signal	4…20 mA / 2-wire
Scaling	Measuring range
Signal error	Error signal according to NAMUR NE43
Burden	Max. 500 Ω
Transmitter output range	Display range
0...300 °C	-60...650 °C
0...600 °C	-60...650 °C
