Technical data
Type	MH3750
Measuring range / resolution	-199.99...199.99 °C / 0.01 °C 200.0...850.0 °C / 0.1 °C
Accuracy	±0.015 % of range ±1 digit
Equipment
Input	Pt100
Multi-conductor connection	4-wire
Output	Analogue output 0...1 V, free scaleable
Measurement features
Data memory	Manual - 99 values, Cyclic - 16 200 values Adjustable measuring interval 1 s...60 min
General data
Units	°C / °F
Sensor Connection	1x mini-DIN-socket, 4-pole
Linearisation	Offset and gradient Characteristic curve according to DIN EN 60751 User-defined characteristic curve
Power Supply	9 V block battery or optional power supply
PC Interface	Galvanically isolated RS232 / USB
Display and Housing
Display	2 x 4½ digit LCD
Functions	Hold, Auto-Off, Alarm and time/date, Min-/max alarm signal via display, interface and buzzer, Real time clock with year and date
Housing Material	Shock-resistant ABS plastic, foil keyboard, clear window, integrated bracket
Dimensions (H x W x T)	142 x 71 x 26 mm
Weight	Approx. 155 g
