Measurement Functions	Signal	+/-(% of reading + c)
Voltage
AC (VAC) true RMS	6 V, 60 V, 600 V	0.5 %
DC (VDC)	60 mV, 600 mV, 6 V, 60 V, 600 V, 1000 V	0.2 %
Current
AC (IAC)	60 mA, 600 mA	0.5 %
DC (IDC)	60 mA, 600 mA	0.2 %
Temperature
TC (°C/°F)	R, S, B, K, E, J, T, N	0.5 %
RTD (°C/°F)	Cu50, Pt100, Pt1000	0.5 %
Resistance
Ohm (Ω)	600 Ω, 6 kΩ, 60 kΩ	0.2 %
	600 kΩ	0.5 %
	6 MΩ	1.0 %
	60 MΩ	2.0 %
Frequency (Hz)	10 Hz, 100 Hz, 1000 Hz, 10 kHz	0.02 %
	up to 2 V	1.0 %
	up to 600 Ω	0.2 %
Technical Data
Display	5-digit multifunction LCD, 65 x 48 mm
Operating panel	Rubber keys and rotary switch
Compartment door	Easy replacement of batteries and fuses
Flashlight / Backlight	Built-in light sources aid in low light environments
Safety standards	IEC 61010, pollution grade two, 600 V CAT. IV, 1000 V CAT. III
Power supply	3 x AA (1.5 V), low battery detection, auto-off function
Service life of batteries	132 hours (typical, measurement), 13 hours (typical, source 20 mA)
Protection level	IP65 dustproof and resistant to water spray
Dimensions	185 mm (H) × 90 mm (W) × 54 mm (D)
Weight	approximately 500 g
