Technical data
Resistance thermometers (RTD)
Generation and measurement of RTD signals	Pt50, Pt100, Pt200, Pt500, Pt1000, Cu10, Cu50, Ni100, Ni120, Ni1000
Ω-generator function	0...4000 Ω
Ω-measurement function	0…4000 Ω
Accuracy (of reading + const.)	±0.012 %
Selectable temperature unit	°C / °F
Measurement of multi-wire connections	2 / 3 / 4
Thermoelemente (TC)
Generation and measurement of TC signals	J, K, T, R, S, B, N, E, U, L
mV-generator function	0...100 mV
mV-measurement function	0…100 mV
Accuracy (of reading + const.)	±0.013 %
Selectable temperature unit	°C / °F
Internal comparison point	±0.3 °C
Current (mA)
Loop current signal generation	0(4)...24 mA
Loop current signal measurement	0(4)…50 mA
Accuracy (of reading + const.)	±0.0175 %
Current loop supply	24 V ±10 %, 22 mA
HART Communication protective resistor	250 Ω
Voltage (V)
Voltage signal generation	0...20 V
Voltage signal measurement	0...50 V
Accuracy (of reading + const.)	±0.015 %
General data
Sensor connection	8 safety sockets (2 channels) incl. push lock, 4 sets with safety instrument leads (4 mm) and alligator clips (optional)
Power supply	Rechargeable battery including power adapter, 230 VAC / 12 VDC
Operator guidance	Menu with pull-down windows Separate channels for parallel signal processing
Display	Multifunction display, double-LCD, 2 x 6 digit, illuminated
Housing
Version	ABS plastic with protective cover
Dimensions	110 x 210 x 50 mm (H x W x D)
Weight	Approx. 900 g
