Technical Data
Type	P4
Pressure ranges	-0.3…4bar
Pressure medium	Air
Connections
Reference pressure gauge	G¼ female thread with PA hose (2 x 1 m)
Test sample	G¼ with quick coupling and pressure hose (1 m)
Basic
Dimensions	Approx. 225 x Ø 55 mm
Weight	Approx. 980 g
Solid
Dimensions (case)	Approx. 450 x 370 x 110 mm
Weight	Approx. 4.2 kg
+Adapter kit	Chrome-plated brass, G⅛, G¼, G⅜, G½, ⅛ NPT, ¼ NPT, ½ NPT, M12 x 1.5, M20 x 1.5, G⅛, G¼
+Seal kit	PA flat gaskets and O-rings
