Technical data
Type	JET2.0
Pressure ranges	Between -1…3000 bar
ACCURACY (linearity and hysteresis)	0.20 % F.S. (Standard Version)
Selectable Pressure units	Bar, mbar, kPa, MPa, PSI, mHg, mmHg, mH2O, mmH2O, kg/cm 2
Measuring inputs	1 x direct
TEMPERATURE INDICATION (Unit °C, °F)
a) Resolution	0.1 °C
b) Accuracy	+-1 °C
REFERENCE TEMPERATURE	0 … +50 °C
OPERATING TEMPERATURE	-10 … +50 °C
RELATIVE UMIDITY	< 90 % not condensed
TEMPERATURE EFFECT (1 °C)
a) on zero	<0,002%
b) on sensitivity	<0,002%
INTERNAL RESOLUTION	16 bit
READING PER SECONDS	10 (100ms)
DISPLAY	13mm (custom LCD)
RESOLUTION Programmable	1, 2, 5, 10
DIGITAL FILTER Programmable	0…99
FUNCTION ZERO	Active up to 100 % F.S.
FUNCTION PEAK	Active in PRESSURE and VACUUM
DATA LOGGER Function
Max Storing Frequency	1 measure for second
Max storing pressure measures	60.000 Records
Max storing pressure+ temperature	30.000 Records
Powre Supply (RECHARGEABLE inside BATTERY)
Autonomy	~ 3 months (Backlight and wireless disabled)
Recharge Battery	Li-Ion 3.7V 1100mA/h
Tiem Recharge	~ 8 hours (With PC or USB power supply)
MECHANICAL LIMIT VALUES:
a) service pressure	100% F.S.
b) limit pressure	150% F.S.
c) breaking pressure	>300% F.S.
d) highly dynamic pressure	75% F.S.
PROCESS COUPLING	1/2" G Male
SEAL RECOMMENDED	USIT A 63-18
TIGHTENING WRENCH	27 mm
TIGHTENING TORQUE	28 Nm
PROTECTION CLASS (EN 60529)	IP40
MATERIAL SENSOR	17-4 PH STAINLESS STEEL
CONTAINER MATERIAL	ALUMINUM
Overview pressure ranges	Full scale	Display	Resolution
TYPE	bar	bar	bar
RV	0.1	0.1000	0.0001
RV	0.25	0.2500	0.0001
RV	0.5	0.5000	0.0001
ARV	1.0	1.000	0.001
ARV	2.5	2.500	0.001
ARV	5	5.000	0.001
ARV	10	10.00	0.01
RV	20	20.00	0.01
R	50	50.00	0.01
R	100	100.0	0.1
R	250	250.0	0.1
R	350	350.0	0.1
R	500	500.0	0.1
R	700	700.0	0.1
R	1000	1000	1
R	1500	1500	1
R	2000	2000	1
R	2500	2500	1
R	3000	3000	1
