Technical Data
Type	VHS06	VK306
Switching function	Contact	Contact
	->closes at increasing flow	->closes at increasing flow
	->opens at decreasing flow	->opens at decreasing flow
	Reversing possible
Pressure rating	PN 25	PN10
Temperature ranges	-25...110 °C (Medium)	-25...110 °C (Medium)
	-25...80 °C (Ambient)	-25…70 °C (Ambient)
Electrical data
Electrical connection	Plug connector DIN EN 175301-803-A incl. cable socket	1.5 m PVC jacket cable
Switching current	1 A
Switching voltage	230 VAC, 48 VDC
Rating	26 VA, 20 W
Degree of protection EN 60529	IP65
Protection class EN 60730-1	Class II
Approvals	WRAS, TUV Rheinland
