Technical Data
Accuracy	±0.5 % of reading
Repeatability	±0.05 % of reading
Response Time	< 50 ms (up to DN 40), > 50 ms (up to DN 300)
Process Connections	Thread (up to DN 50): BSP ISO 228, Flange: DIN
Pressure Drop	280 mbar at 100% measurement range (density 1, viscosity 1 mm²/s)
Minimum Pressure	2 x pressure drop of sensor
Pressure Rating	Threaded Connection: 250 bar; Flanged Connection: Corresponding to flange specification
Medium Temperature	See technical data of the pick-up (max. 250°C)
Materials	Pipe Tee: Stainless steel ANSI 316; Flange: Stainless steel ANSI 316
Rotor (VTR1010-VTR1020)	Stainless steel (18% Cr, 2% Mo)
Rotor (VTR1025-VTR1300)	Stainless steel (20% Cr, 2% Mo)
Bearing Support	Stainless steel ANSI 316
Rotor Bearing	Tungsten carbide
Protection Class	IP65
Highlights	Robust stainless steel body, high measuring accuracy, calibration certificate (5-point calibration)
