Technical Data
Accuracy class (OIML R60)	C2	C3	C4
Legal Divisions	2000	3000	4000
Nominal Load (Emax)	10, 25, 50 kg; 100, 200, 300, 500 kg; 1, 2, 2.5, 5, 7.5, 10 t
Combined Error	≤ ± 0.023%	≤ ± 0.018%	≤ ± 0.015%
Non-repeatability	≤ ± 0.015%	≤ ± 0.010%	≤ ± 0.010%
Zero Return over 30min.	≤ ± 0.025%	≤ ± 0.015%	≤ ± 0.010%
Creep at nominal load over 30min	≤ ± 0.025%	≤ ± 0.015%	≤ ± 0.015%
Creep at nominal load over 20 and 30min	≤ ± 0.005%	≤ ± 0.005%	≤ ± 0.003%
Nominal Sensitivity	2 mV/V
Sensitivity Tolerance	≤ ± 0.1%
Temperature Effect on Zero (10°C)	≤ ± 0.028%
Temperature Effect on Sensitivity (10°C)	≤ ± 0.012%
Linearity	≤ ± 0.03%
Hysteresis	≤ ± 0.03%
Repeatability	≤ ± 0.01%
Input Resistance	420 ± 20 Ω
Output Resistance	350 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ± 1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1–15 V
Maximum Supply Voltage	18 V
Minimum Load	0%
Service Load	120%
Max Permissible Load	150%
Breaking Load	>300%
Max Transverse Load	100%
Max Permissible Dynamic Load	50%
Displacement at Nominal Load	∼ 0.2 mm
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight (Ø63.5 mm)	∼ 0.6 kg
Weight (Ø82 mm)	∼ 1.2 kg
Weight (Ø102 mm)	∼ 2.6 kg
Weight (Ø127 mm)	∼ 4.4 kg
Protection Class (EN 60529)	IP68 (100h at 1m water column), IP65 (10, 25, 50 kg with silicon cover)
Execution Material	Stainless Steel
Cable Length	5 m (on request 10 m)
