Technical Data
Temperature range	-35...165 °C at ambient temperature 20 °C
	See the respective calibration function for details.
Calibration volume	Ø 60 x 170 mm (calibration insert easily exchangeable)
Dry block Air Shield Insert	External reference temperature sensor
Temperature range: -30...160 °C
Display accuracy	±0.07 °C
Temperature stability	±<0.001…0.005 °C
Temperature distribution
->Axial	±0.060 °C
->Radial	±0.010 °C
Influence of load	±0.010 °C
Dry block	External reference temperature sensor	Internal reference temperature sensor
Temperature range: -30...165 °C
Display accuracy	±0.10 °C	±0.27 °C
Temperature stability	±0.005 °C	±0.010 °C
Temperature distribution
->Axial	±0.200 °C	±0.200 °C
->Radial	±0.050 °C	±0.050 °C
Influence of load	±0.080 °C	±0.150 °C
Calibration bath (stirred), direct filling	External reference temperature sensor	Internal reference temperature sensor
Temperature range: -35...155 °C
Display accuracy	±0.19 °C	±0.24 °C
Temperature stability	±0.010 °C	±0.020 °C
Temperature distribution
->Axial	±0.325 °C	±0.325 °C
->Radial	±0.080 °C	±0.080 °C
Influence of load	±0.040 °C	±0.200 °C
Calibration bath (stirred), tub insert	External reference temperature sensor	Internal reference temperature sensor
Temperature range: -35...155 °C
Display accuracy	±0.19 °C	±0.28 °C
Temperature stability	±0.010 °C	±0.020 °C
Temperature distribution
->Axial	±0.350 °C	±0.350 °C
->Radial	±0.080 °C	±0.080 °C
Influence of load	±0.040 °C	±0.300 °C
Infrared calibration	External reference temperature sensor	Internal reference temperature sensor
Temperature range: -35...165 °C
Display accuracy	±0.5 °C	±0.5 °C
Temperature stability	±0.020 °C	±0.020 °C
Emission factor	0.9994
Surface calibration	External reference temperature sensor
Temperature range: -25...150°C
Display accuracy	±1 °C
Temperature stability	±0.150 °C
Stabilisation time (with external reference temperature sensor)
->to ±0.05°C	From 1 min
->to ±0.005°C	From 5 min
Heating time
->20 °C…155 °C	27 min
->-35 °C…155 °C	34 min
Cooling time
->165 °C…30 °C	17 min
->20 °C…-25 °C	35 min
Resolution of the temperature display	0.001 °C
Hysteresis	±0.010 °C
Temperature units	°C / °F / K (selectable)
Reference temperature sensor	internal, fixed installation / external (selectable)
Interfaces	Ethernet, 3 x USB
Connectivity	OPC UA, HTTP. Details and further possibilities on request.
Dimension
->Width	210mm
->Height	380 + 50mm (Handle)
->Depth	300mm
Weight	Approx. 13kg
Power supply	100...240 VAC, 50 / 60 Hz
Power consumption	Approx. 375 W
Adjustable temperature range	-50...165 °C
Display	Brilliant color touchscreen (7 inches), multi panel safety glass
Approvals	CE, RoHS, REACH, EAC, UKCA, CT
Integrated measuring instrument
Device under test inputs - Resistance thermometers
Number of channels	2
Connection	4 mm safety socket, 4 per channel
Connection type	2-, 3-, 4-wire technology
Resistance range
->Pt100	0…400 Ω
->Pt1000	0…4000 Ω
Accuracy
->Pt100	±0.03 °C
->Pt500	±0.12 °C
->Pt1000	±0.06 °C
->Ni100	±0.02 °C
->Ni150	±0.08 °C
->Ni1000	±0.04 °C
Device under test inputs - Thermocouple
Number of channels	2
Connection	2x thermocouple socket (mini)
Connection type	-10…100 mV
Accuracy cold junction	±0.3 °C
Accuracy
->Type K	±0.08 °C
->Type J	±0.07 °C
->Type N	±0.13 °C
->Type E	±0.06 °C
->Type T	±0.09 °C
->Type R	±0.78 °C
->Type S	±0.73 °C
->Type B	±0.5 °C
Standard signal input (Current)
Number of channels	1
Connection	4 mm safety socket
Measuring range	0…24 mA
Accuracy	0.01 % of range
Standard signal input (Voltage)
Number of channels	1
Connection	4 mm safety socket
Measuring range	0…12 VDC
Accuracy	0.01 % of range
Switch test
Number of channels	2
Transmitter supply
Output current	Max. 24 mA
Output voltage	24 VDC
