Technical Data
Temperature range	-55...200 °C at ambient temperature 20 °C
Dimension of the calibration insert	Ø 28 x 150 mm (calibration insert easily exchangeable)
Dry block
Accuracy	±0.4 °C
Temperature stability	±0.1 °C
Resolution of the temperature display	0.1 °C
Reference temperature sensor	internal, fixed installation
Dimensions
->Width	210mm
->Hight	380 + 50mm (Handle)
->Depth	300mm
Weight	Approx. 12.5 kg
Power supply	100...240 VAC, 50 / 60 Hz
Power consumption	Approx. 555 W
Display and control	2-line, 4-digit digital display red / green, unit °C / °F
Approvlas	CE, RoHS, REACH, EAC, UKCA, CT
Calibration insert
Bore holes (mm)	Material
1x Ø 3.5, 1x Ø 6.5, 1x Ø 13.5	Brass
1x Ø 6.5	Brass
2x Ø 3.5	Brass
1x Ø 3.5, 1x Ø 4.5	Brass
1x Ø 3.5, 1x Ø 6.5	Brass
1x Ø 3.5, 1x Ø 8.5	Brass
Without bore holes	Brass
Calibration insert incl. 1 bore hole of choice	Brass
Each additional bore hole	Brass
