| Technical Data | |
| Temperature range | -35...165 °C at ambient temperature 20 °C |
| Dimension of the calibration insert | Ø 28 x 150 mm (calibration insert easily exchangeable) |
| Dry block | |
| Accuracy | ±1 °C |
| Temperature stability | ±0.1 °C |
| Resolution of the temperature display | 1 °C |
| Reference temperature sensor | internal, fixed installation |
| Dimensions | |
| ->Width | 210mm |
| ->Hight | 380 + 50mm (Handle) |
| ->Depth | 300mm |
| Weight | Approx. 10 kg |
| Power supply | 100...240 VAC, 50 / 60 Hz |
| Power consumption | Approx. 375 W |
| Display and control | 2-line, 4-digit digital display red / green, unit °C / °F |
| Approvlas | CE, RoHS, REACH, EAC, UKCA, CT |
| Calibration insert | |
| Bore holes (mm) | Material |
| 1x Ø 3.5, 1x Ø 6.5, 1x Ø 13.5 | Brass |
| 1x Ø 6.5 | Brass |
| 2x Ø 3.5 | Brass |
| 1x Ø 3.5, 1x Ø 4.5 | Brass |
| 1x Ø 3.5, 1x Ø 6.5 | Brass |
| 1x Ø 3.5, 1x Ø 8.5 | Brass |
| Without bore holes | Brass |
| Calibration insert incl. 1 bore hole of choice | Brass |
| Each additional bore hole | Brass |
