Technical Data
Nominal Load (Emax)	250, 500 kg, 1, 2.5, 5, 7.5, 10, 15, 20, 30, 50, 75, 100 t
Combined Error	≤ ±0.03%
Non-Repeatability	≤ ±0.01%
Zero Return Over 30 Min	≤ ±0.03%
Creep At Nominal Load (30 Min)	≤ ±0.03%
Temperature Effect On Zero (10°C)	≤ ±0.05%
Temperature Effect On Sensitivity (10°C)	≤ ±0.03%
Nominal Sensitivity	2mV/V
Sensitivity Tolerance	≤ ±0.1%
Input Resistance	700 ± 3 Ω
Output Resistance	700 ± 3 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ±1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1-15 V
Maximum Supply Voltage	18 V
Displacement At Nominal Load	∼0.06 mm, ∼0.16 mm, ∼0.23 mm
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight	∼1.2 kg, ∼2.0 kg, ∼3.8 kg, ∼9.4 kg
Protection Class (EN 60529)	IP68 (100h at 1m water column)
Execution Material	Stainless Steel
Cable Length	5m (on request 10 m)
