Technical Data
Accuracy Class (OIML R60)	C2	C3
Legal Divisions	2000	3000
Nominal Load (Emax)	5, 7.5, 10, 15, 20 t
Minimum Verification Interval (Vmin)	Emax / 10000
Combined Error	≤ ±0.023%	≤ ±0.019%
Non-Repeatability	≤ ±0.014%	≤ ±0.011%
Zero Return Over 30 Min	≤ ±0.030%	≤ ±0.013%
Creep to Nominal Load (30 Min)	≤ ±0.024%	≤ ±0.014%
Creep to Nominal Load (over 20 and 30 min. )	≤ ±0.011%	≤ ±0.008%
Temperature Effect on Zero (10°C)	≤ ±0.028%	≤ ±0.016%
Temperature Effect on Sensitivity (10°C)	≤ ±0.008%	≤ ±0.008%
Nominal Sensitivity	2mV/V
Sensitivity Tolerance	≤ ±0.1%
Input Resistance	420 ± 20 Ω
Output Resistance	350 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ±1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1-15 V
Maximum Supply Voltage	18 V
Minimum Load	0%
Service Load	120%
Max Permissible Load	150%
Breaking Load	>300%
Max Transverse Load	50%
Displacement at Nominal Load	∼0.3 mm
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight	∼4.4 kg	∼7.0 kg
Protection Class (EN 60529)	IP68 (100h at 1m water column)
Execution Material	Stainless Steel
Cable Length	5m (on request 10m)
