Technical Data
Accuracy Class	0.1%
Linearity And Hysteresis	0.1%
Nominal Load	20 t, 30 t	50 t, 75 t, 100 t
Temperature Effect On Zero (10°C)	≤ ±0.028%
Temperature Effect On Sensitivity (10°C)	≤ ±0.008%
Nominal Sensitivity	2 mV/V
Calibration Tolerance	≤ ±0.1%
Input Resistance	420 ± 20 Ω
Output Resistance	350 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ±1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1–15 V
Maximum Supply Voltage	18 V
Minimum Load	0%
Service Load	120%
Max Permissible Load	150%
Breaking Load	> 200%
Max Transverse Load	50%
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Working Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight	∼10 kg	~ 19 kg
Protection Class (EN 60529)	IP65
Execution Material	Stainless Steel
Connector	MIL-C-5015 7 poles male
