Technical Data
Nominal Load (Emax)	350, 500 kg; 1, 2.5, 5 t; 7.5, 10, 20 t
Nominal Sensitivity	2 mV/V
Sensitivity Tolerance	≤ ± 0.1%
Temperature Effect on Zero (10°C)	≤ ± 0.030%
Temperature Effect on Sensitivity (10°C)	≤ ± 0.011%
Linearity	≤ ± 0.03%
Hysteresis	≤ ± 0.03%
Repeatability	≤ ± 0.01%
Input Resistance	440 ± 20 Ω
Output Resistance	350 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ± 1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1–15 V
Maximum Supply Voltage	18 V
Service Load	120%
Max Permissible Load	150%
Breaking Load	> 300%
Max Transverse Load	50%
Max Permissible Dynamic Load	50%
Displacement at Nominal Load	∼ 0.3 mm
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight (350–5 t, Ø57)	∼ 1.5 kg
Weight (5–10 t, Ø82)	∼ 4.2 kg
Weight (20 t, Ø82)	∼ 5 kg
Protection Class (EN 60529)	IP67
Execution Material	Stainless Steel
Cable Length	5 m (on request 10 m)
