Technical Data
Nominal Load (Emax)	1, 2, 5 kg (complete with overload protection for tension and compression, max. 500% F.S.)
Nominal Load (Emax)	10, 25, 50 kg
Nominal Sensitivity	2 mV/V
Sensitivity Tolerance	≤ ± 0.1%
Temperature Effect on Zero (10°C)	≤ ± 0.025%
Temperature Effect on Sensitivity (10°C)	≤ ± 0.021%
Linearity	≤ ± 0.03%
Hysteresis	≤ ± 0.03%
Repeatability	≤ ± 0.01%
Input Resistance	440 ± 20 Ω
Output Resistance	350 ± 2 Ω
Insulation Resistance	> 5 GΩ
Zero Balance	≤ ± 1%
Recommended Supply Voltage	10 V
Nominal Supply Voltage	1–15 V
Maximum Supply Voltage	18 V
Service Load	120%
Max Permissible Load	150%
Breaking Load	>300%
Max Transverse Load	50%
Max Permissible Dynamic Load	50%
Displacement at Nominal Load	∼ 0.3 mm
Reference Temperature	+23°C
Temperature Nominal Range	-10/+40 °C
Service Temperature	-20/+70 °C
Storage Temperature	-20/+80 °C
Weight	∼ 0.3 kg
Protection Class (EN 60529)	IP20
Execution Material	Aluminum
Cable Length	3 m
