Technical data
Type	F2
Pressure Ranges	-1...0 to 0...600 bar (압력범위 표 참조)
Accuracy	±0.8 % FS typical (±1 % FS nominal)
Selectable Units	bar, mbar, PSI, kgf/cm², kPa, Mpa (압력범위에 따라 상이)
Display
Type	4-digit LCD with backlight, bar graph, battery indicator
Display Rate	2 readings per second
Measuring system
Pressure measuring cell	≤250 bar: Ceramic sensor
	>250 bar: Stainless steel sensor
Operating Temperature	10...70 °C (14...160 °F)
Compensation Temperature	18...30 °C (65...90 °F)
Long-term Stability	±0.2 % FS / year
Measuring Medium	Non-explosive gases, water, oil (non-highly viscous & non-corrosive)
Process Connection
Process Connection	G¼ or ¼″ NPT (via adapter)
Connection Material	Stainless steel 1.4301 / AISI 304
Housing
Electrical Protection	EN 61326
Housing Material	Stainless steel 1.4301 / AISI 304
Weight	0.3 kg (0.7 lbs)
Power Supply
Power Supply	2x AAA batteries (not included)
Battery Life	Approx. 2400 hours
Overview pressure ranges		Burst pressure	Selectable Units
Pressure range	-1…0 bar	1 bar	bar, mbar, PSI, kgf/cm², kPa, Mpa
	-1...3 bar	6 bar	bar, mbar, PSI, kgf/cm², kPa, Mpa
	0...6 bar	12 bar	bar, mbar, PSI, kgf/cm², kPa, Mpa
	0…10 bar	20 bar	bar, PSI, kgf/cm², kPa, Mpa
	0…16 bar	32 bar	bar, PSI, kgf/cm², kPa, Mpa
	-1…25 bar	50 bar	bar, PSI, kgf/cm², kPa, Mpa
	-1…40 bar	80 bar	bar, PSI, kgf/cm², kPa, Mpa
	0…60 bar	120 bar	bar, PSI, kgf/cm², kPa, Mpa
	0…100 bar	150 bar	bar, PSI, kgf/cm², Mpa
	0…160 bar	240 bar	bar, PSI, kgf/cm², Mpa
	0…250 bar	375 bar	bar, PSI, kgf/cm², Mpa
	0…400 bar	600 bar	bar, PSI, kgf/cm², Mpa
	0…600 bar	900 bar	bar, PSI, kgf/cm², Mpa
	0…700 bar	1050 bar	bar, PSI, kgf/cm², Mpa
	0…1000 bar	1500 bar	bar, PSI, kgf/cm², Mpa
